MOTHERBOARD ASUS P9A-I/C2750/SAS/4L

Descripción

Procesador / Sistema Bus1 x Socket C2750 Intel® ATOM™ C-Series FCBGA Processor(Avoton)MemoriaTotal Slots : 2 (2 Channels) Capacity : Maximum up to 32GB UDIMMMemory Type :DDR3 1600/1333 UDIMM with ECCMemory Size :16GB, 8GB, 4GB, 2GB UDIMMPuertos de ExpansiónTotal Slot : 1Slot Location 7 : PCI-E x8 (Gen2 X4 Link) Form FactorMini ITX (6.7″” x 6.7″”) Capacidades ASUSFAN speed controlASWM EnterpriseAlmacenamiento SATA Controller :2 x SATA3 6Gb/s portsor 1 x SATA3 6Gb/s ports + 1 x M.2 connectorSAS Controller :4 x MiniSAS connector(Marvell 88SE9485 x 2)GráficaAspeed AST2300 with 32MB VRAM I/O Internos1 x PSU Power Connector (24-pin ATX power connector + 4-pin ATX 12V power connector)5 x Fan Header , 4pin1 x Chassis Intruder4 x Front LAN LED1 x Serial Port Header1 x SATA DOM Power connector1 x M.2 connectorPuertos posteriores I/O2 x USB 2.01 x VGA Port4 x GbE LAN + 1 x Mgmt LANSolución de ManejoASWM EnterpriseASMB7-iKVM for KVM-over-InternetRegulatory ComplianceCE, FCC(Class B)AmbienteOperation temperature: 10℃ ~ 35℃Non operation temperature: -40℃ ~ 70℃Non operation humidity: 20% ~ 90% ( Non condensing) AccesoriosStandard Gift Box Pack (1pcs per Carton)3 x Support CD1 x I/O shield2 x SATA 6G cables1 x COM port cable1 x CPU fan*Install a CPU fan when the airflow through the heatsink is below 1.5 CFM.Standard Bulk Pack (10pcs per Carton)3 x Support CD1 x I/O shield1 x CPU fan*Install a CPU fan when the airflow through the heatsink is below 1.5 CFM.Product SKUsStandard Gift Box Pack with ASMB7-iKVMStandard Bulk Pack with ASMB7-iKVMMonitoringCPU TemperatureFan RPM
